Descripción
Factor de forma M.2 2280
Interfaz NVMe PCIe 4.0 x4
Capacidade 1TB
Velocidad secuencial de lectura/escritura
1TB – 6-000/4-000MB/seg
NAND 3D
Resistencia (total de bytes escritos)
1TB a 320TB
Temperatura de almacenamiento -40° a 85°C
Temperatura de funcionamiento 0 a 70°C
Dimensiones 22mm x 80mm x 2-3mm
Peso 7g (todas las capacidades)
Vibración fuera de operación 20G (10 -1000Hz)
MTBF (Expectativa de Vida) 2-000-000 horas

Especificaciones generales
Plataforma: Computadora de escritorio
# de núcleos de CPU: 8
# de hilos: 16
Reloj de aumento máx.: Hasta 4.6 GHz
Reloj base: 3.7 GHz
Caché L1 total: 512 KB
Caché L2 total: 4 MB
Caché L3 total: 16 MB
TDP predeterminado: 65W
AMD Configurable TDP (cTDP): 45-65W
Tecnología de procesador para núcleos de CPU: TSMC 7nm FinFET
Desbloqueado para overclocking: Sí
CPU Socket: AM4
Solución térmica (PIB): AMD Wraith Stealth
Temp. máx.: 95°C
*Compatible con SO
Windows 10 edición de 64·bits
RHEL x86 edición de 64·bits
Ubuntu x86 edición de 64·bits


Conectividad
Versión de PCI Express: PCIe 3.0
Tipo de memoria: DDR4
Canales de memoria: 2
Especificación de memoria de sistema: Hasta 3200 MT/s


Tecnologías compatibles
AMD StoreMI Technology
AMD Ryzen™ VR-Ready Premium

Gabinete Gamer Solarmax CM-B950-SF

Dise?o: Cubo
Factor: EATX/ATX/M-ATX/ITX
PSU: ATX 12V- PS/2
Puertos: Type-C + USB 3.0 + USB 2.0 + HD Audio
Malla: Anti-Polvo Superior e Inferior
Paneles Frontal y Lateral: Vidrio Templado
Discos: 2xHDD + 2xSSD
VGA: 410mm
Watercooler: 360mm
CPU Cooler: 163mm
Dimensiones: 426*285*398
ARGB Fan: 4pcs incluidas

ATENCION: Este producto viene en caja en caja black OEM
---------------------------------------------------------------------------------

GeForce RTX 3080
La Jugada Definitiva
Las tarjetas gr?ficas GeForce RTX? 3080 ofrecen el alto rendimiento que buscan los gamers. Basado en Ampere- la segunda generaci?n de la arquitectura RTX de NVIDIA- cuentan con N?cleos RT mejorados y N?cleos Tensor- nuevos multiprocesadores de transmisi?n y memorias GDDR6X s?per r?pidas- para una experiencia de juego simplemente incre?ble.

Chipset: GeForce GeForce? RTX 3080
Core Clock: 1800 MHz
CUDA Cores: 8704
Tama?o y tipo de memoria: 10Gb GDDR6
Interfaz de memoria: 320 bit
Velocidad de memoria: 760 GB/s
Microsoft DirectX: 12
OpenGL: 4
Interfaz: 3x Display Port- 2x HDMI
Tama?o de la placa: 320 W=129 H=55 mm
Conectores de fuente: 8-pin x2
Fuente recomendada: 750w

Tarjeta madre AMD AM4 mATX con PCIe 4.0- dual M.2- WiFi- HDMI- D-Sub- DVI- SATA 6 Gbps- puertos USB 3.2 Gen 2 e iluminaci?n Aura Sync RGB

- Socket AMD AM4: Listo para procesadores Ryzen? de escritorio Series 5000- 4000G y 3000.
- Refrigeraci?n completa: Disipador de VRM- disipador de PCH y Fan Xpert 2+.
- Conectividad ultrarr?pida: Dual M.2- PCIe 4.0- Wi-Fi 802.11ac- USB 3.2 Gen 2 tipo A.
- Aura Sync RGB: Efectos LED sincronizables en una amplia gama de equipos de PC compatibles- incluidas tiras RGB direccionables.

- CPU: AMD AM4 Socket for AMD Ryzen? 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors *
* Refer to www.asus.com for CPU support list

- Chipset: AMD B550

- Memoria:
4 x DIMM- Max. 128GB- DDR4 4866(O.C)/4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4333(O.C.)/4266(O.C.)/4200(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory *
Dual Channel Memory Architecture
ECC Memory (ECC mode) support varies by CPU.
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists)- and memory frequency support depends on the CPU types.

- Gr?ficos:
1 x D-Sub
1 x DVI-D
1 x HDMI 2.1(4K@60HZ)

- Slots de Expansi?n:
AMD Ryzen? 5000 Series/ 3000 Series Desktop Processors
1 x PCIe 4.0 x16 (x16 mode)
AMD Ryzen? 5000 G-Series/ 4000 G-Series Desktop Processors
1 x PCIe 3.0 x16 (x16 mode)
AMD B550 Chipset
2 x PCIe 3.0 x1

- Almacenamiento:
Total supports 2 x M.2 slot(s) and 4 x SATA 6Gb/s ports
AMD Ryzen? 5000 Series/ 3000 Series Desktop Processors :
1 x M.2_1 socket 3- with M Key- Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
AMD Ryzen? 5000 G-Series/ 4000 G-Series Desktop Processors:
1 x M.2_1 socket 3- with M Key- Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support

- AMD B550 Chipset :
1 x M.2_2 socket 3- with M Key- Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support
4 x SATA 6Gb/s port(s)-
Support Raid 0- 1- 10

- LAN:
Realtek RTL8111H 1Gb Ethernet
Datos de redes inl?mbricas
Wi-Fi 802.11 a/b/g/n/ac
Supports dual band frequency 2.4/5 GHz
Supports PCIe interface

- Bluetooth: Bluetooth? 5.0
- Audio: Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC *
- Supports : Jack-detection- Multi-streaming- Front Panel Jack-retasking- up to 24-Bit/192kHz playback
- Audio Feature :
- LED-illuminated design
- Audio Shielding
- Dedicated audio PCB layers
- Premium Japanese audio capacitors
* Choose the chassis with HD audio module in front panel to support 8-channel audio output.

- Puertos USB:
Rear USB Port ( Total 6 )
2 x USB 3.2 Gen 2 port(s)(2 x Type-A)
4 x USB 3.2 Gen 1 port(s)(4 x Type-A)
Front USB Port ( Total 6 )
2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
4 x USB 2.0 port(s)(4 x Type-A)

- Software Features:
ASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
AI Suite 3
- Performance And Power Saving Utility
TurboV EVO
EPU
Digi+ VRM
Fan Xpert 2+
- EZ update
ASUS CPU-Z
AI Charger
DAEMON Tools
Norton Anti-virus software (Free Trial for 60 days)
WinRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode

- ASUS Special Features:
ASUS 5X PROTECTION III
- ASUS DIGI+ VRM
- ASUS LANGuard
- ASUS Overvoltage Protection
- ASUS SafeSlot Core
- ASUS Stainless-Steel Back I/O
ASUS Q-Design
- ASUS Q-DIMM
- ASUS Q-Slot
ASUS Thermal Solution
- Aluminum heatsink design
AURA Sync
- Standard RGB headers
- Addressable Gen 2 RGB header
ASUS Lighting Control

- Puertos I/O Traseros:
1 x PS/2 keyboard/mouse combo port(s)
1 x DVI-D
1 x D-Sub
1 x HDMI
1 x LAN (RJ45) port(s)
2 x USB 3.2 Gen 2 (teal blue) (2 x Type-A)
4 x USB 3.2 Gen 1 (blue) Type-A
3 x Audio jack(s)
1 x ASUS Wi-Fi Module

- Internal I/O:
1 x CPU Fan connector(s)
1 x CPU OPT Fan connector(s)
2 x Chassis Fan connector(s)
2 x Aura RGB Strip Headers
1 x Addressable Gen 2 header(s)
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
1 x M.2 Socket 3 with M key- type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode)
1 x M.2 Socket 3 with M key- type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x SPI TPM header
4 x SATA 6Gb/s connector(s)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 8-pin EATX 12V Power connectors
1 x Front panel audio connector(s) (AAFP)
1 x Clear CMOS jumper(s)
1 x System panel connector
1 x COM port header
1 x Speaker connector

- Accessorios:
I/O Shield
2 x SATA 6Gb/s cable(s)
1 x Supporting DVD
User manual
1 x Wi-Fi moving antenna
1 x M.2 SSD screw package(s)

- BIOS: 256 Mb Flash ROM- UEFI AMI BIOS
- Capacidad de gesti?n: WOL by PXE
- Sistema Operativo: Windows? 10 64-bit
- Factor de forma: mATX Form Factor
9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )

FEATURES:
• Product line: Viper Elite II
• Edition: Red heatshield with black Viper logo / top
• Aluminum heat spreader with unique and
specific design element
• Feature Overclock: XMP 2.0 support for automatic
overclocking
• Compatibility: Tested across the latest Intel and AMD
platforms for reliably fast performance
• Limited lifetime warranty
SPECIFICATIONS:
• Capacity: 8GB (1 x 8GB)
• Base Frequency: PC4-21300 (2666MHz)
• Base Timings: 19-19-19-43
• Tested Frequency Profile 1: PC4-25600 (3200MHz)
• Tested Timings: 18-22-22-42
• Tested Voltage for Profile 1: 1.35V
• Format: NON-ECC Unbuffered DIMM
• Pin Out: 288-Pin

compatibility
intel lga1700/1200/1151/1150/1155/1156 amd am5/am4
tdp 220w
overall dimension 120?75?151mm (l?w?h)
heatsink material 4??6mm heatpipe (direct touch) + aluminum fin
weight 650g (heatsink+fan)
fan dimension 120?120?25mm
fan speed 600?200 ~ 1500?10% rpm
max. air flow 70cfm
max. static pressure 2.15mmh2o
noise 28.9db(a) max.
rated voltage 12vdc (4pin pwm)
operating voltage 10.8 ~ 13.2vdc
started voltage 7vdc
rated current 0.2a
power input 2.4w
bearing type hydraulic
connector 4pin pwm
